HYAR5 is a Omni-directional reader with the most advance technology, applying in wide alleyway,Loing distance, quick identification, meeting the special demand of identification, tracking and positioning among many tags simultaneously

• Maximum identification distance is 2 to 80 meters and can be easy adjusted by command through the computer at the scene.
• Support identification of fast moving objects with speed up to 200 kilometers
• Work at globally free 2.45GHz ISM band,125 channels, 8MHz channel bandwidth
• Data rate is 1Mbps , adjustable RF power is -20dBm-0dBm ,max transmission power is 1mW
• Communicate with othere quipment through RS232/RS485/WEIGEN-26/TCP/IP/GPRS
• Asynchronous communication rate 9600BPS-38400BPS(Please confirm your interface before order)
• Communicate with computer through RS232/485/weigand 26 or wirelessly
• Encrypted and certified to assure data safety, preventive of eavesdropping and intentional decoding
• Applied channel isolation technology, no interferences between equipments
• Advanced anti-collision techniques, Support multi-tags read and write
• Customized microwave work modes, adjustable transmission power
• Meet harsh industrial environment requirements,Applied design techniques of anti-interferences and thunders

Specification

Electric characteristics

Environment characteristics

Others
